1200 PP Power Pack

Introduction

YONGAN power pack is manufactured to optimize the hydraulic pressure for a constant stability of the job performance on high efficiency of operation with YONGAN piling equipment. It is made by our high-tech CNC operated machinery. Open loop hydraulic system ensures easy assembly and maintenance. Equipped with high quality hydraulic pump and top brand engine, maximum efficiency and reliability of hydraulic pile driver power unit is ensured. The power unit is using sound proof frame with heavy steel enclosure, noise levels are significantly reduced for a friendly operation environment. High cooling capacity of hydraulic system provides a stable hydraulic system and together with oversized radiator ensures no overheating problems. Hose power varies from 120P to 1320P for wide selection of YONGAN vibro hammer or impact hammer range.

Click to enlarge

Technical Parameters of 1200PP Power Pack

The engine power of hydraulic pile driver power unit is 1200HP. Its operating pressure is 24mpa and the oil tank capacity turns to be 2300L.

1200PP Power Pack	Engine Type	KTA38-1200
	Engine Power (HP)	1200
	Operating Pressure (Mpa)	24
	Maximum Oil Flow (L/min)	1100
	Hydraulic Oil Tank Volume (L)	2300
	Fuel Tank Volume (L)	800

» Advantages

1.Powerful Diesel Engine
Yongan power pack is equipped with Caterpillar or Cummins engine which generates greater productivity by higher horse power and torque ratings.
2. Rexroth Hydraulic Pump
Yongan chooses Rexroth hydraulic pump to obtain a great performance. We offer both fixed and variable displacement pump accordingly to customer’s requirement.
3. Cooling System
Oversized radiator is used in yongan power pack ensuring it can work from -30° up to 50°
4. Reliable Filtration
Famous brand of filters are used to guarantee a long lasting efficiencies against contaminated oils and large amount of dust. It ensures filtration system for hydraulic and engine fuel system.
5.Manifold Block Utilize
Build-in manifold block is used for easy system control and to supply accurate system flow and pressure to the machine.
6.Simple Design of Control Panel
The power pack control panel is designed according to the easy operation principle and people’s using habit. We are using indication gauge to showing electrical and hydraulic system.
7.Remote Control
Remote control has the functions as emergency stop, engine speed adjust, clamp on/off, vibro operation. It ensures operator control piling or extracting in a long distance from piling area.

» Maintenances

1. Hydraulic oil should be changed in time.
2. Please check the tightness of the sealing elements regularly.
3. Oil tank should be tightly sealed to incoming of water and clutter.
4. Suction port of oil pump should be sealed to prevent air.

» Payment and Delivery

30% deposit payment should be paid after signing the contract. Full payment should be paid before delivery. Machine package and delivery can be arranged as you require.
